Omega Fire
Water-Based Acrylic/Silicone Hybrid
Omega Fire is a two-component coating (A&B) having a blend of seven different ceramics combined in a water-based, acrylic/hybrid modified silicone formula to create a barrier against extreme flame impingement and heat migration. The coating can withstand direct flame up to 2200°F by hardening on the surface at first contact, while continuing to provide the necessary insulation value. The resin blend binds the compounds together and forms a char to matrix the ceramics across the face of the coating, facing the flame.
Omega Fire is designed to stay intact with constant adhesion at extreme temperatures, while remaining flexible. In this way, it can move with the surface, during expansion and contraction, without cracking and falling off as the substrate moves.
Product Resources
Typical Uses
-
Strategic Locations on Warfare Ships
-
Engine Rooms and Galleys
-
Corner Beams, Elevator Shafts, Stairwells
-
To control and contain fires in high-rise buildings
-
To prevent the spread and collapse of support structures
-
NYC Approval for Two Hours on Support Beams
-
Over high-rise cladding to prevent spread of fire
Intumescent Thermal Barrier for Spray Polyurethane Foam
DC 315 applied over Spray Polyurethane Foam (SPF), is an Alternative Barrier System to meet the “NBC of Canada 2010 Section 3.1.5.12” as a thermal barrier. To be approved as an Alternative Barrier System, DC 315 is applied over SPF, and is tested to the criteria of CAN/ULC S101 for a minimum duration of 10 minutes by an accredited fire testing facility. Independent test results show DC 315 will delay the involvement of SPF in a fire situation and will successfully protect against flashover, melting and smoke development. DC 315 has received a CAN/ULC S 101 listing for 25 minute duration and is certified and marked by Warnock Hersey Intertek (WHI). As an Alternative Approval product, IFTI insists on consulting the Authority Having Jurisdiction prior to installing DC 315 in accordance with “Division C Section 2.3 of the NBC of Canada”.
Advantages
-
Single coat coverage reducing labour and material costs equaling higher profits
-
Excellent spread rate
-
Passed CAL 1350 safe for use in schools and high occupancy buildings
-
Passed strict EPA - V.O.C. and AQMD air emission requirements
-
Approved for Incidental Food Contact, complies with NSF/ANSI-51 requirements of USDA
-
Easily applied with sprayer, roller or brush with no complicated mixing
-
1 year shelf life
-
Fast and easy clean-up with no waste and fast turnaround time
-
Compatible with any paintable construction material
-
Warnock Hersey listed and marked WHI
-
Meets Life Safety Code 101
-
Meets LEED's point requirements
-
No formaldehyde
Interior Intumescent - Class "A" Flame Spread Rating
Safecoat PVC is an acrylic, solvent based paint which can be used in interior applications to achieve a Flame Spread rating of 0 and a Smoke Developed Rating of 35 tested under CAN/ULC S102.2. This intumescent fire retardant coating is manufactured specifically for PVC pipe and fittings. It is especially effective where exposure to moisture and UV radiation is a concern or the coating is subject to repeated cleaning. it limits flame spread by expanding to any times the original dry film thickness when exposed to heat. This expanded material forms a char which insulates the substrate against heat, and reduces available oxygen to the surface, thus limited flame spread to a CLASS A on PVC, as tested under CAN/ULC S102.2 standard, in a single coat application sprayed at 100 sq. ft. per USG.
Typical Uses
-
Imparts a Class A Flame Spread Rating of 0 and Smoke Developed Rating of 35 when applied to PVC
-
Can be used in Return Air Plenums, High Rises, and Non-combustible buildings where traditionally only copper and/or cast iron pipe was used.
-
Can be applied as a mandatory upgrade to assist owners and property managers to meet the latest fire and building code requirements.
-
Factory or job-site application
Intumescent up to a 2 Hour Fire Resistance Rating (120 minutes) on Structural Steel
Safecoat Steel is a single component latex, intumescent fire retardant coating ideally suited for exposed interior structural steel where up to a 2 hour fire resistance rating is required. It is ideal for interior steel columns, trusses, beams and other exposed structural members. It limits thermal penetration by expanding to many times the original dry film thickness when exposed to heat. This expanded material forms a char which insulates the substrate against heat, and reduces available oxygen to the surface. It provides up to a 2 hour fire rating as tested under ASTM E-119-08A, NFPA 251 “Small Scale Test” and CAN/ULC4-S101 “No Load”.
NCFR 1000-1X solvent paint is an exceptionally durable, high quality paint for interior and exterior use. It is also an extremely effective class A/Type 1 fire retardant coating. Through its intumescent action (foaming and frothing when subjected to flame) NCFR 1000-1X provides excellent fire protection. The vinyl co-polymer resin system gives excellent durability for exterior as well as interior applications. An important additional advantage is that transparent material can be applied over wood surfaces and may also be applied over rigid polyurethane foam and other plastic materials to achieve low flame spread ratings. Simple application with brush, spray or roller is all that is required.
Recommended for:
The best choice for situations where sources of fire may be present, as well as in cases where the consequences of brush or forest fires may be severe. Always make your own test.
Typical Uses
Hotels, Hospitals, Schools, Government Institutions, etc.
Exterior / Interior Intumescent Latex - Class "A" Flame Spread Rating
NCFR 102 is a Class A, interior/exterior intumescent latex fire protective coating. NCFR 102 comes in black or white and can be tinted with universal colorants to fit any decorating scheme. NCFR 102 is an excellent choice for interior/exterior applications on foam, wood, paneling, primed metal, stucco, concrete, plastics and drywall where a Class A flame spread is desired.
RESISTANCE:
Weather: Good
Humidity: Good
Abrasion: Good
Weight Solids: 64%
Volume Solids: 52%
VOC: 80g
Flash point: 211 °F
Viscosity: 90-95 KU
Shelf life: 6 months
SIGNIFGANT APPLICATIONS:
Los Angeles School District
San Francisco General Hospital
Sam’s Town New Casino, NV
Clark County School District, NV
Hilton Hotel, NV
NOT RECOMMENDED FOR:
Immersion Service
Flexible Substrates
High Moisture Areas
Interior Clear Intumescent - Class "A" Flame Spread Rating
SafeCoat® Clear II Fire Retardant Coating is a two-component, ultra-low VOC, clear intumescent coating designed for application to wood surfaces where a Flame Spread Rating of 25 or less (Class A) is required. SafeCoat® Clear II limits the spread of flame by expanding and forming a char when exposed to heat. The expanded char insulates the wood from heat and reduces the oxygen available for combustion at the wood surface.
APPLICATION:
-
Spraying achieves the most uniform finish
-
HVLP, airless, or air-assisted with a minimum 12 thou tip
-
Use a high-quality brush or roller recommended for solvent-borne paints
FEATURES:
-
Clear intumescent coating that exhibits excellent flame spread protection for interior wood substrates
-
Cures to a semi-gloss to satin finish, matte reducer is available upon request
-
Extremely durable – scratch, mar, and stain resistant
-
High solids – ultra-low VOC formula aids in meeting LEED™ criteria
Exterior / Interior Surface Clear Water Based Latex - Class "A" Flame Spread Rating
Fire retardant coating for exterior or interior wood and thatch products. X-238 is a white, opaque, water-based fire retardant coating for use on exterior and interior wood and thatch products. It is paint-like in appearance and dries to a clear satin finish in approximately four (4) – fourty eight (48) hours depending on ambient temperature and relative humidity.
X-238 is flexible yet durable which enables it to breathe, shed heavy, driven rain, and withstand considerable sand and dust abrasion.
-
Product Certifications
Exterior/Interior Penetrating Clear Latex - Class "A" Flame Spread Rating
FIREX-FS II ® Fire Retardant Coating, a post treatment exterior/interior fire retardant and preservative. This product dries clear. When used on porous woods such as Douglas Fire or Pine, it will provide a Class A rating. FS II penetrates wood and becomes part of its molecular structure, it also closes wood pores making them insoluble to water, therefore it can be said that this product is a wood preservative. This product contains proprietary vinyl-copolymer latex that will protect the fire retardant from exterior weather for up to 10 years and a min of 5 years. When treated material is subjected to an open flame, the retardant will pyrolitically self-extinguish fire with minimum smoke. FS II is commonly non-toxic, non-hazardous and easy to apply.
BASIC USES:
FS II should be used for exterior/interior applications such as: most porous woods, cedar shake shingles for preservative and fire retardant.
ADVANTAGES:
Class A one coat system. 25 Flamespread, 25 Smoke Development. Since FS II penetrates and becomes part of the substrate, the life of the flame retardancy is indefinite if interior, if exterior we recommend retreatment after 5 years. FS II is user friendly, water based and non-toxic. This product dries clear and may be coated with most latex coatings or latex stains, after the product has cured and if applied properly due to its unique polymer bond for an indefinite time interior and a minimum of 5 years exterior. Most fire retardants that are thick paints will deteriorate over time because they do not become part of the wood. This product will not alter the structural integrity of the wood like pressure treatment does.
LIMITATIONS:
Do NOT dilute. Storage range: 110°F to 45 °F Shelf life: 1 year if kept within storage temperatures. We suggest a small compatability test. Moisture content should be 8%-19% before treatment. Woods that have a low moisture content need to be treated with a heavier coverage.
APPLICABLE STANDARDS:
FS II has been tested to the following standards:
ASTM E-84, NFPA 255, UL 723, US Testing #LA 62466, Omega Point Laboratories #8746-108578, Calafornia Registration #C-256.01, LA Approval, RR#25420 and CSI#09960.
-
Safecoat Latex Project
Interior Intumescent Class "A" Flame Spread Rating and 1¾ Hour Fire Resistance Rating
SAFECOAT LATEX ® Fire Retardant Coating is a single component latex-based, intumescent fire retardant coating ideally suited for interior applications to SPF Plywood (Spruce/Pine/Fir), Oriented Strand Board (OSB), wood trusses and rough stud construction, where Flame Spread Ratings of 25 or less (“Class A” or Class 1) and low Smoke Developed Ratings are required. It limits flame spread by expanding to many times the original dry film thickness when exposed to heat. This expanded material forms a char which insulates the substrate against heat, and reduces available oxygen to the surface, thus limiting flame spread to a “CLASS A” rating on OSB, SPF plywood and Douglas Fir Decking as tested under ASTM E84-91a and CAN4-S102-M88 standards in a single coat application sprayed at 150 ft USG. SAFECOAT Latex dries quickly to a flat (matte) finish, having the appearance of conventional flat paint.
APPLICATIONS:
• Imparts a Class A Flame Spread Rating to dimensional lumber, plywood and Oriented Strand Board (OSB).
• Acts as a thermal barrier to protect foamed plastic insulation when used in conjunction with OSB.
• Used in lieu of drywall on plywood and OSB for greater strength and resilience.
• Replaces sprinklers in combustible concealed spaces, under NFPA-13.
• Can be applied as a mandatory upgrade to assist owners and property managers to meet the latest fire and building code requirements. It may also be applied as a voluntary upgrade to lower fire risks and reduce insurance costs.
FEATURES:
• Is non-toxic. It contains NO asbestos, harmful ingredients or solvents.
• Is cost-effective. A single coat applied at 150 ft’/USG achieves a “Class A” Flame Spread Rating.
• Is fire-resistant. It will not burn in liquid or solid state. Under fire conditions, it forms a char, preventing the spread of flames, and slowing the penetration of heat through the substrate (Fire Endurance).
• Has excellent adhesion and durability.
• May be tinted with a latex based “Universal Tint”.
• Will adhere to metal and acts as a rust-inhibitor.
• Is easy to apply – may be applied by brush, roller or spray.
Penetrating Chemical Broad Spectrum - Class "A" Flame Spread Rating
Safecoat FR-41 is designed for use on a wide variety of substances. It is extremely effective on wood, wood base products, straw, hay, dry vegetation, paper, cardboard and practically all water absorbent materials where fire protection is desired.
Safecoat FR-41 is formulated as an absorbent fire retardant and provides excellent protection against grass and wildfires. It is non-toxic and contains no harmful ingredients. Re-treatment is required following rain or laundering.
Safecoat FR-41 can be applied by spraying, padding, immersion or incorporated directly into the product. The method of application depends on the type of material and the structure of the fibre to be protected.
-
Safecoat FR-31 Projects
Commercial
-
Display Banner
Industrial
-
Product Certifications
Penetrating Chemical Fabric Treatment - Class "A" Flame Spread Rating
This product is a highly effective, economical, and environmentally friendly fire retardant treatment for fabric of most types. It can be used as a fire retardant and impregnating agent on practically all water-absorbent materials.
SAFECOAT FR-31 can be applied by spraying, padding or immersion, or it can be incorporated directly into a product. The method of application depends on the type of material and structure of the fiber to be protected.
Features:
• is an aqueous solution of inorganic salts. It is colorless and has a slight odor of ammonia in solution but is odorless when dry.
• is chemically neutral or slightly alkaline with a pH of 7.0 to 8.0. Its primary role is to act as a flame retardant.
• does not substantially affect the appearance or feel of the fabric if properly applied. The fabric remains soft and pliable.
• Since SAFECOAT FR-31 Fire Retardant Fabric Treatment is water-soluble it can be washed out of both textiles and materials. Re-treat after laundering.
• is provided in a Ready-to-Use, liquid form.
